Star Screening Buckets

MGM VL 3-215

Screening bucket with larger rotor diameter and powerful motors, ideal for crushing stone and processing heavy materials in demanding applications.

High capacity for heavy-duty applications
Large screening surface for fast processing
Suitable for intensive daily use
Strong with wet and sticky materials
Reliable choice for large projects

Excavator
28.00 - 40.00 tonnage
Wheelloader
16.00 - 24.00 tonnage

Bucket volume
2900 l
Sieve surface
1,9 m²
Hydraulic oil flow
200-280 l/min
Standard weight
3130 kg

Product specifications

Model	VL 3-215
Length	1700 mm
Width	2570 mm
Height	1500 mm
Indication capacity	100-350 m³ p/u

Binnenwerken

C-Rotor (Crushing blade)

Designed for reducing materials such as glass,
gypsum, ceramics, and other soft rocks. Also
suitable for further size reduction of compost,
organic waste, or other material flows.

CH-Rotor (Crushing Hammer blade)

This coarse version of the crushing blade is
equipped with perpendicular hammer plates.
Suitable for rapidly reducing semi-hard or
clumped materials.

K-Rotor (Cutting blade)

The chopping drum is more aggressive than
the standard crushing blade and operates in
both directions. It efficiently pulverizes
clumped materials into a fine, dust-like
consistency.

Q-Rotor (Qualitie soft zeefblad)

This rotor is ideal for screening applications
where minimal damage or breakage is desired.
For example, when separating invasive plants,
it is important to keep them intact.

S-Rotor (Standard screening blade)

Suitable for screening stones or hard residual
materials from top layers on construction and
demolition sites, as well as compost and
garden soil. This rotor is known as the “all-
rounder.
”

X-Rotor (Mixrotor)

Specifically designed for soil improvement by
mixing clay or other materials with binders or
soil types. Its aggressive action breaks down
hard clumps effectively.

About MGM VL 3-215

The MGM VL3-215 screening bucket is perfectly suited for excavators from 28 to 40 tons and loaders from 16 to 24 tons, such as the Volvo L90 to L120 and the CAT 938 to 966. With a bucket capacity of 2900 liters and a larger rotor diameter compared to the VS and VM series, this screening bucket ensures higher efficiency and productivity. Thanks to its robust construction and powerful hydraulic motors, the VL3-215 is ideal for processing heavy materials such as soil, demolition waste, and wet materials, providing the perfect solution for the most demanding applications.
